OSG 1608607 | M10 x 1.50mm Thread Size x 22.50mm Thread Length M D6 Bottom (1.5P) Chamfer Type 4 Flute Right Hand Nitride/Steam Oxide Coated HSS 141C Straight Flute Tap

$38.73 $17.43
(You save $21.30)
Brand:
OSG
Overall Length (mm):
74.60mm
Number of Flutes:
4
Material:
HSS
Finish/Coating:
Nitride / Steam Oxide
interval quantity:
1
SKU:
15029473
UPC:
Weight:
0.08 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
OSG 1608607 | M10 x 1.50mm Thread Size x 22.50mm Thread Length M D6 Bottom (1.5P) Chamfer Type 4 Flute Right Hand Nitride/Steam Oxide Coated HSS 141C Straight Flute Tap

GENERAL PURPOSE Taps Straight Flute Hand Taps for Cast Iron


Product Specifications
Manufacturer Part Number1608607
Chamfer Length (Decimal Inch)0.089"
Major Diameter (mm)10.00mm
Neck Length (mm)35.10mm
Number of Flutes4
Overall Length (mm)74.60mm
Pitch (mm)1.50mm
Shank Diameter (mm)9.68mm
Square Length (mm)11.11mm
Square Width (mm)7.26mm
Maximum Tap Drill Size (mm)8.68mm
Minimum Tap Drill Size (mm)8.38mm
Thread Length (mm)22.50mm
Thread SizeM10
CoatingNitride / Steam Oxide
MaterialHSS
Series141C Series
Product TypeStraight Flute Tap
