OSG 1660000400 | A BRAND M8 x 1.25mm Thread Size x 15.00mm Thread Length M D5 Bottom (1.5P) Chamfer Type 3 Flute Right Hand Bright Coated Carbide 16600 Spiral Flute Tap

$216.78 $201.61
(You save $15.17)
Brand:
OSG
Flute Direction:
Right Hand
Number of Flutes:
3
Overall Length (mm):
90.00mm
Material:
Carbide
Finish/Coating:
Bright
Thread Limit:
D5
interval quantity:
1
SKU:
18002094
UPC:
Weight:
0.12 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
OSG 1660000400 | A BRAND M8 x 1.25mm Thread Size x 15.00mm Thread Length M D5 Bottom (1.5P) Chamfer Type 3 Flute Right Hand Bright Coated Carbide 16600 Spiral Flute Tap

A Brand A-CSF is an Advanced Performance Carbide Coolant-Through Taps for Cast Iron and Aluminum Alloy.

Features & Benefits:

  • Larger Oil Hole Design: Excellent coolant flow
  • Bright finish: Greater performance in non-ferrous materials
  • Ultra-Fine Grain Carbide: For high wear resistance and toughness

Product Specifications
Manufacturer Part Number1660000400
Chamfer Length (Decimal Inch)0.074"
Chamfer TypeBottom (1.5P)
Coolant ThroughYes
Cutting DirectionRight Hand
Helix Angle (Degree)15 Degree
Helix DirectionRight Hand
List NameA-CSF
Major Diameter (mm)8.00mm
Neck Length (mm)35.00mm
Number of Flutes3
Overall Length (mm)90.00mm
Pitch (mm)1.25mm
Shank Diameter (mm)8.08mm
Square Length (mm)9.53mm
Square Width (mm)6.05mm
MaterialCarbide
CoatingBright
Tap Drill Size Maximum (mm)6.91mm
Tap Drill Size Minimum (mm)6.65mm
Thread Length (mm)15.00mm
Thread LimitD5
Thread SizeM8
Thread TypeM
Series16600
Product TypeSpiral Flute Tab
