OSG 2691805 | HY-PRO M10 x 1.50mm Thread Size x 9.68mm Shank x 18.00mm Thread Length x 6H Class of FitM Plug (4P) Chamfer Type 3 Flute TiN Coated HSSE 269 Spiral Point Tap

$107.91 $65.83
(You save $42.08)
Brand:
OSG
Class of Fit:
6H
Through Coolant:
Yes
Cutting Direction:
Right Hand
Number of Flutes:
3
Material:
HSSE
Finish/Coating:
TiN
interval quantity:
1
SKU:
15030409
UPC:
Weight:
0.11 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
OSG 2691805 | HY-PRO M10 x 1.50mm Thread Size x 9.68mm Shank x 18.00mm Thread Length x 6H Class of FitM Plug (4P) Chamfer Type 3 Flute TiN Coated HSSE 269 Spiral Point Tap

HY-PRO DIN is the original "Do it All" premium spiral point "gun" tap for a wide range of materials.

Features & Benefits:

  • HSSE material: Increased wear resistance
  • Spiral Point: For through hole applications
  • TiN Coating: Improves wear resistance for extended tap life
  • DIN Overall Length: Provides additional reach capability

Product Specifications
Manufacturer Part Number2691805
Chamfer Length (Decimal Inch)0.236"
Chamfer TypePlug (4P)
Class of Fit6H
Coolant ThroughYes
Cutting DirectionRight Hand
List NameOIL-TIN-POT
Major Diameter (mm)10.00mm
Neck Length (mm)38.90mm
Number of Flutes3
Overall Length (mm)100.00mm
Pitch (mm)1.50mm
Shank Diameter (mm)9.68mm
Square Length (mm)11.11mm
Square Width (mm)7.26mm
MaterialHSSE
CoatingTiN
Tap Drill Size Maximum (mm)8.68mm
Tap Drill Size Minimum (mm)8.38mm
Thread Length (mm)18.00mm
Thread SizeM10
Thread TypeM
Series269
Product TypeSpiral Point Tap
