Pramet WCMT 32.52-45:D8330 | 0.375" Circle Diameter x 0.031" Radius Indexable Drill Insert

$14.12
Ships:
From Partner Facility
Ships:
From Partner Facility
interval quantity:
10
SKU:
23146183
Weight:
0.13 LBS
Minimum Purchase:
10 units
Shipping:
Free Shipping
Drilling insert WCMT 06T3.., D8330 PVD coated fine grained WC-Co carbide within ISO-grade ranges P20-P35 and K15-K35 with 45 geometry for machining of steel and cast-iron.

Product Specifications
EDP Number6754639
Coating Property1
Fixing Hole Diameter (mm)4.4 mm
Fixing Hole Diameter (Inch)0.173"
Cutting Edge Length (mm)6.5 mm
Cutting Edge Length (Inch)0.256"
Inscribed Circle Diameter (mm)9.525 mm
Inscribed Circle Diameter (Inch)0.375"
Insert Thickness (mm)3.97 mm
Insert Thickness (Inch)0.156"
Corner Radius (mm)0.8 mm
Corner Radius (Inch)0.031"
Coating ProcessPVD
CoatingD8330
Surface ColorGold
