Features:
- Accuracy to ± 0.0001
- Compensates for thermal expansion
- Low profile
Product Specifications
| # MFG | 17412 |
| Type | Type V Standard Center |
| Taper | 12 Brown & Sharpe |
| Accuracy | ± 0.0001 |
| Overall Length (Inch) | 8.020" |
| Point Length (Inch) | 2.000" |
| Gage Line to Point (Inch) | 2.880" |
| Max Thrust Load (lbs) | 1088 lbs. |
| Max Spring Travel (Inch) | 0.188" |
| Max Workpiece Weight (lbs) | 1450 lbs. |
| Max RPM | 1500 |
| Point Diameter (Inch) | 1.075" |
| Series | Concentric Spring Loaded Live Centers |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Riten
Length (Inch):
2"
Length (Decimal Inch):
2.0000"
Length (mm):
50.80mm
Overall Length (Inch):
1"
Overall Length (Decimal Inch):
8.0200"
Overall Length (mm):
203.71mm
Diameter (Inch):
1-5/64"
Diameter (Decimal Inch):
1.0750"
Diameter (mm):
27.31mm
