Compact, medium-length clamping arm that allows operating pressures up to 5000 psi. This arm provides a low profile and is also ideal for clamping in horizontal slots.
Mount arm on the tapered piston rod at desired orientation, then fasten with the piston-rod nut included with swing clamp.
| Material | Heat Treat | Finish | DFARS | RoHS |
| Forged 4142 Alloy Steel | - | - | Yes | Yes |
| Clampsize | A | B | C | D | E | F | G | H | I | Weight(lbs) |
| 2 & 3 Series | 2.03 | 0.83 | 1.26 | 0.55 | 1.32 | 0.63 | 0.610 | 0.57 | 0.28 | 0.2 lbs. |
