Seco Tools 10001138 | MTH-M4X0.70ISO6HX-BC-S101 M4 Thread Size x 0.162" Diameter x 0.177" Shank x 2.545" OAL 15 Degree Helix Angle 3 Flute ACN Coated HSS-E-PM Spiral Flute Tap

$68.50 $49.32
(You save $19.18)
Brand:
Seco Tools
Number of Flutes:
3
Material:
HSS-E-PM
Finish/Coating:
ACN
Overall Length (Decimal Inch):
2.5450"
Overall Length (mm):
64.64mm
interval quantity:
1
SKU:
17993775
UPC:
Weight:
0.01 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout
Seco Tools 10001138 | MTH-M4X0.70ISO6HX-BC-S101 M4 Thread Size x 0.162" Diameter x 0.177" Shank x 2.545" OAL 15 Degree Helix Angle 3 Flute ACN Coated HSS-E-PM Spiral Flute Tap

Product Specifications
Manufacturer Part Number10001138
Thread Diameter (Decimal Inch)0.162"
Thread Diameter (mm)4.10mm
Threading Chamfer Length (Decimal Inch)0.069"
Threading Chamfer Length (mm)1.75mm
Tap Chamfer Length (Decimal Inch)0.069"
Tap Chamfer Length (mm)1.75mm
Connection Diameter Machine Side (Decimal Inch)0.177"
Connection Diameter Machine Side (mm)4.50mm
Shank Diameter (Decimal Inch)0.177"
Shank Diameter (mm)4.50mm
Functional Length (Decimal Inch)2.411"
Functional Length (mm)61.25mm
Usable Length (Decimal Inch)0.512"
Usable Length (mm)13.00mm
Overall Length (Decimal Inch)2.545"
Overall Length (mm)64.64mm
Thread Length (Decimal Inch)0.512"
Thread Length (mm)13.00mm
Thread Diameter SizeM4
Recommended Premachined Hole Diameter (Decimal Inch)0.134"
Recommended Premachined Hole Diameter (mm)3.40mm
Connection Size Code4.50X3.40
Connection Size Code Machine Side4.50X3.40
Maximum Premachined Hole Diameter (Decimal Inch)0.135"
Maximum Premachined Hole Diameter (mm)3.42mm
Minimum Thread Pitch (Decimal Inch)0.028"
Minimum Thread Pitch (mm)0.70mm
Maximum Thread Pitch (Decimal Inch)0.028"
Maximum Thread Pitch (mm)0.70mm
Flute Helix Angle (Degree)15 Degree
Number of Flute3
Shank TypeCylindrical
Thread Tolerance Class6HX
Threading Chamfer TypeC
Thread Form TypeM
Cutting DirectionRight Hand
Cutting Geometry TypeISO-S
Cutting Geometry Type TechnicalSpiral
MaterialHSS-E-PM
CoatingACN
Product TypeSpiral Flute Tap
