Product Specifications
| Diameter (Decimal Inch) | T7426247 |
| Diameter (Decimal Inch) | 0.1807" |
| Diameter (mm) | 4.59mm |
| Overall Length (Decimal Inch) | 2.3800" |
| Overall Length (mm) | 60.45mm |
| Thread Length (Decimal Inch) | 0.8800" |
| Thread Length (mm) | 22.35" |
| Square Length (Decimal Inch) | 0.8800" |
| Square Length (mm) | 22.35" |
| Shank Diameter (Decimal Inch) | 0.1940" |
| Shank Diameter (mm) | 4.93mm |
| Square Size (Decimal Inch) | 0.1520" |
| Square Size (mm) | 3.86mm |
| Drill Size (Decimal Inch) | 0.1457" |
| Drill Size (mm) | 3.70mm |
| Useable Length (Decimal Inch) | 0.8800" |
| Useable Length (mm) | 22.35mm |
| Length/Diameter | 2.0xD |
| Coolant Through | No |
| Tap Type | STFL |
| Number Of Flutes | 3 |
| Size | #6 |
| Pitch | 32 TPI |
| Thread Series | UNC |
| Pitch Limit | H3 |
| Chamfer Type | Plug |
| Chamfer Length | 4P-5P |
| Finish | Bright |
| Material | HSS |
| Blank Standard | 322 |
| Product Type | Spiral Flute Tap |
