Seco Tools 02573296 | 0.707" Inscribed Circle Diameter x 0.020" Radius x 0.187" Thickness 8 Cutting Edge PCBN Milling Insert

$599.00
Brand:
Seco Tools
Material:
PCBN
Inscribed Circle (Decimal Inch):
0.7070"
Inscribed Circle (mm):
17.96mm
Thickness (Inch):
3/16"
Thickness (Decimal Inch):
0.1870"
Thickness (mm):
4.76mm
interval quantity:
2
SKU:
23278009
UPC:
Weight:
0.03 LBS
Minimum Purchase:
2 units
Shipping:
Free Shipping
Seco Tools 02573296 | 0.707" Inscribed Circle Diameter x 0.020" Radius x 0.187" Thickness 8 Cutting Edge PCBN Milling Insert

Product Specifications
Manufacturer Part Number02573296
Inscribed Circle Diameter (Decimal Inch)0.707"
Inscribed Circle Diameter (mm)17.96mm
Wiper Edge Length (Decimal Inch)0.063"
Wiper Edge Length (mm)1.60mm
Cutting Edge Effective Length (Decimal Inch)0.212"
Cutting Edge Effective Length (mm)5.39mm
Shank Width (mm)38.50mm
Functional Width (mm)23.80mm
Corner Radius (Decimal Inch)0.020"
Corner Radius (mm)0.50mm
Insert Thickness (Decimal Inch)0.187"
Insert Thickness (mm)4.76mm
Clearance Angle Major (Degree)24 Degree
Cutting Edge Condition CodeT
Cutting Edge Count8
Pocket Seat Code of The CutterOF..0704
Insert Size And ShapeOFEN0704
MaterialPCBN
Product TypeMilling Insert
