Seco Tools 03272998 |OFEN070405TN-D18 0.707" Inscribed Circle Diameter x 0.020" Corner Radius x 0.187" Thickness 8 Cutting Edge Carbide Face Milling Insert

$42.30 $34.72
(You save $7.58)
Brand:
Seco Tools
Material:
Carbide
Inscribed Circle (Decimal Inch):
0.7071"
Inscribed Circle (mm):
17.96mm
Thickness (Inch):
3/16"
Thickness (Decimal Inch):
0.1874"
Thickness (mm):
4.76mm
interval quantity:
10
SKU:
23287197
UPC:
Weight:
0.03 LBS
Minimum Purchase:
10 units
Shipping:
Free Shipping
Seco Tools 03272998 |OFEN070405TN-D18 0.707" Inscribed Circle Diameter x 0.020" Corner Radius x 0.187" Thickness 8 Cutting Edge Carbide Face Milling Insert

Product Specifications
Manufacturer Part Number03272998
Inscribed Circle Diameter (Decimal Inch)0.707"
Inscribed Circle Diameter (mm)17.96mm
Cutting Edge Effective Length (Decimal Inch)0.276"
Cutting Edge Effective Length (mm)7.00mm
Wiper Edge Length (Decimal Inch)0.079"
Wiper Edge Length (mm)2.00mm
Corner Radius (Decimal Inch)0.020"
Corner Radius (mm)0.50mm
Insert Thickness (Decimal Inch)0.187"
Insert Thickness (mm)4.76mm
Cutting Edge Count8
Clearance Angle Major (Degree)26 Degree
Insert HandNeutral
Cutting Geometry TypeD
Cutting Geometry Type TechnicalD18
Pocket Seat Code of The CutterOF..0704
Insert Size And ShapeOFEN0704
Insert Shape CodeO
MaterialCarbide
Product TypeFace Milling Insert
