| Manufacturer Part Number | T7405317 |
| Thread Size | M6 |
| Thread Size (Decimal Inch) | 0.236" |
| Thread Size (mm) | 6.00mm |
| Pitch (mm) | 1.00mm |
| Thread Series | M |
| Pitch Limit | D3 |
| Chamfer Type | Plug |
| Chamfer Length | 4P-5P |
| Overall Length (Decimal Inch) | 2.720" |
| Overall Length (mm) | 69.09mm |
| Thread Length (Decimal Inch) | 1.130" |
| Thread Length (mm) | 28.70mm |
| Square Length (Decimal Inch) | 0.380" |
| Square Length (mm) | 9.65mm |
| Shank Diameter (Decimal Inch) | 0.318" |
| Shank Diameter (mm) | 8.08mm |
| Square Size (Decimal Inch) | 0.238" |
| Square Size (mm) | 6.05mm |
| Drill Size (Decimal Inch) | 0.248" |
| Drill Size (mm) | 6.30mm |
| Connection Size (Decimal Inch) | 0.318" x 0.238" |
| Connection Size (mm) | 8.08 x 6.05mm |
| Usable Length (Decimal Inch) | 1.130" |
| Usable Length (mm) | 28.70mm |
| Length / Diameter | 2.0 x D |
| Number of Flutes | 3 |
| Coating | Bright |
| Material | HSS |
| Blank Standard | 322A |
| Series | T7405 |
| Product Type | Hand STI Tap |
