Single-sided negative barpeeling insert, rectangular with a length of 38.25 mm, 12 mm thick for 4 mm depth of cut,, chip-breaker PR, in grade 6630, a MT-CVD coated functionally graded WC-Co carbide within ISO range P15-P35, for steels.
Product Specifications
| EDP Number | 6752820 |
| Min Cutting Depth (mm) | 0.7 mm |
| Max Depth of Cut (mm) | 4 mm |
| Max Depth of cut (Inch) | 0.157" |
| Coating Property | 1 |
| Cutting Edge Length (mm) | 38.25 mm |
| Cutting Edge Length (Inch) | 1.506" |
| Insert Width (mm) | 17.5 mm |
| Insert Width (Inch) | 0.689" |
| Insert Thickness (mm) | 12 mm |
| Insert Thickness (Inch) | 0.472" |
| Major Cutting Edge Angle | 20 |
| Wiper Edge Length (mm) | 21 mm |
| Wiper edge Length (Inch) | 0.827" |
| Coating Process | MT-CVD |
| Coating | 6630 |
| Surface Color | Gold |
| Min Depth of Cut (mm) | 0.5 mm |
| Min Depth of Cut (Inch) | 0.02" |
| Chipbreaker Manufacturer's Designation | PR |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Ships:
From Partner Facility
Brand:
Pramet
Length (Inch):
1-1/2"
Length (Decimal Inch):
1.5060"
Length (mm):
38.25mm
Thickness (Inch):
15/32"
Thickness (Decimal Inch):
0.4720"
Thickness (mm):
12mm
interval quantity:
5
