Seco Tools 00092120 | 0.504" Inscribed Circle Diameter x 0.020" Radius x 0.156" Thickness 1 Cutting Edge PCD Milling Insert

$264.60
Brand:
Seco Tools
Material:
PCD
Inscribed Circle (Inch):
1/2"
Inscribed Circle (Decimal Inch):
0.5040"
Inscribed Circle (mm):
12.79mm
Thickness (Inch):
5/32"
Thickness (Decimal Inch):
0.1560"
Thickness (mm):
3.97mm
interval quantity:
2
SKU:
23275765
UPC:
Weight:
0.01 LBS
Minimum Purchase:
2 units
Shipping:
Free Shipping
Seco Tools 00092120 | 0.504" Inscribed Circle Diameter x 0.020" Radius x 0.156" Thickness 1 Cutting Edge PCD Milling Insert

Product Specifications
Manufacturer Part Number00092120
Fixing Hole Diameter (Decimal Inch)0.177"
Fixing Hole Diameter (mm)4.50mm
Inscribed Circle Diameter (Decimal Inch)0.504"
Inscribed Circle Diameter (mm)12.79mm
Wiper Edge Length (Decimal Inch)0.095"
Wiper Edge Length (mm)2.40mm
Cutting Edge Effective Length (Decimal Inch)0.138"
Cutting Edge Effective Length (mm)3.50mm
Maximum Depth of Cut (Decimal Inch)0.118"
Maximum Depth of Cut (mm)3.00mm
Corner Radius (Decimal Inch)0.020"
Corner Radius (mm)0.50mm
Insert Thickness (Decimal Inch)0.156"
Insert Thickness (mm)3.97mm
Clearance Angle Major (Degree)26 Degree
Cutting Edge Condition CodeF
Cutting Edge Count1
Cutting Geometry TypeM
Cutting Geometry Type TechnicalM05
Pocket Seat Code of The CutterOF..05
Insert Size And ShapeOFEX05T3
Insert HandNeutral
MaterialPCD
Product TypeMilling Insert
